6006200 m-Series (Mini) Battery Switch Single Circuit ON/OFF Switches a single battery to a single load group. Multiple switches can be used to manage several isolated circuits including cross connecting for emergency parallel Ignition protected – Safe for installation aboard gasoline powered vehicles and boats. Case design allows surface front panel or rear panel mounting. Isolating cover with snap-on sections protects rear contacts 3/8″-16 tin-plated copper studs for maximum conductivity and corrosion resistance accepts 3/8″ and M10 ring terminals. 7/8″ (22.22mm) stud length to accept multiple cable terminals. Ideal for marine, RV and emergency vehicle applications. Manufactured with non-corrosive marine grade metals. Molded in durable reinforced polycarbonate. Tactile textures indicate knob position by feel only. Label with international ON/OFF.
Features:
- Ultra Compact Design
- Selectable Battery ON/OFF
- Safe to use on gas powered vehicles, boats or PWC’s
- Can be mounted in engine compartments and marine environments
Specifications:
- Amp Rating: 300 Continuous Rating (500A intermittent/5 min)
- Amp Cranking Rating: 1500A (up to 10 seconds), 775A (up to 1 min)
- Switch Type: 2 Position (Single circuit ON-OFF)
- Voltage: 12~48 VDC
- Battery Inputs: 1
- Terminal Stud Size: 3/8″ – 16 (M10)
- Weight: 0.65 lb
