- The Series 285 has a unique yellow reset mechanism which provides visual indication of tripped condition. Series 285 also features a red push-to-trip option.
- Drop in replacement for 185-Series Circuit Breakers
- Visible reset lever shows open condition
- Ignition protected – Safe for installation aboard gasoline powered boats
- Meets SAE J1171 external ignition protection requirements
- Weather Resistant – IP67 Rated
- Combines switching and circuit breaker function into one unit
- ‘Trip Free’ – cannot be held closed after trip
Equivalent Models
BRAND MODEL Blue Sea Systems 7187-BSS EATON CB285F-100 EATON 285100F-121-1
Eaton Bussmann 285 Series Hi-Amp Circuit Breaker, Type III Reset, 100A
$37.99
Eaton 285 series 100A marine rated circuit breaker provides medium duty circuit protection for auxiliary and accessory circuits in trucks, buses, RVs, and marine systems. Ideal when switching and circuit protection are both required. Visible yellow reset lever shows open condition with trip-free design that cannot be held closed after trip. Direct drop in replacement for 185 series.
| Specification Heading | Specification Detail |
| Length | 3.2 in |
| Width | 1.9 in |
| Height | 1.34 in |
| Weight | 0.5 lbs |
| Current Rating | 100A |
| Voltage Rating | 48V DC |
| Interrupt Rating | 3000A @ 48V DC |
| Operating Temperature Range | –40°F (–40°C) to 185°F (85°C) |
| Materials | Black UL-rated 94V0 thermoset plastic |
| Terminal Stud | M6 threaded stainless steel studs (Accepts 1/4" Rings) |
| Terminal Stud Torque | 50 in-lbs (5.6N•m) max |
| Ingress Protection | IP67 |
| Compliances | SAE J1625; ABYC E-11; CE; SAE J1171 (Ignition Protected) |
| Mounting Type | Surface |
