Blue Sea 5045 4 Circuit ST Blade Compact Fuse Blocks

$25.99

Compact 4 circuit fuse block provides surface mount circuit protection for ATO/ATC fuses in a compact
footprint. The single side design allows wire entry on one side to maximize space.

Availability: 146 in stock

SKU: 5045-BSS Categories: , , , , ,
Range Discount
1 - 4 $25.99
5 - 9 $25.27
10 - 49 $24.51
50 - 99 $22.02
100 - 199 $20.58
200 + $19.19

Provides surface mount circuit protection for ATO®/ATC® Fuses in a compact footprint.

  • Ignition protected when cover is secure –meets ISO 8846 and SAE J1171 for use in a gasoline engine compartment
  • Single side design allows wire entry from one side to minimize footprint
  • Insulating cover meets ABYC/USCG insulation requirements
  • Tin-plated copper buses and fuse clips
  • Accepts ring or snap fork type terminals
  • Includes 4 write-on circuit labels
  • Fuses sold separately
Specification Heading Specification Detail
Maximum Voltage 32V DC
Maximum Amperage 100A per block / 30A per circuit
Number of Circuits 4
Mounting #8 Screw (M4)
Terminal Stud Torque 24 in-lb (2.71 Nm)
Screw Terminal Torque 18 in-lb (2.03 Nm)
Screw Terminal Type #8-32 Scews with captive star lock washer
Terminal Stud Size #10-32
Dimensions (L x W x H) 3.64" x 1.73" x 1.28"
